Equine LTS Therapy Boot LED Light Therapy Supreme

• LED light therapy boot for horses
• controllable via a mobile app that works on Android and Apple devices
• the app can be used to control various programmes and switch between light colours
• different programmes for the individual use of each light, as well as all 3 frequencies and pulsating light function
• developed to prevent and protect against various injuries using the latest NASA LED technology
• with equal light strands with a total of 108 diodes
• LEDs are powerful, resulting in a large light dispersion in combination with extremely high performance
• combines blue, red and infrared light to optimise the energy absorption of the cells and promote muscle regeneration
• the special LEDs emit light in precisely defined wavelengths, the positive effect of which on the healing process in horses and other mammals has been scientifically documented
• the system is equipped with LEDs in 3 different wavelengths:
• blue light- 450 nm: treats the outermost layers of the skin, can have an antibacterial effect, promote tissue repair and wound healing and is ideal for treating skin-related problems
• red light - 660 nm: can improve circulation, reduce inflammation, provide energy for cell repair and regeneration, reduce muscle soreness and stiffness and promote muscle recovery
• infrared light - 850 nm: penetrates deep into the tissue, acts on tendons, joints and bones, can increase cell metabolism, repair and regeneration
• the 3 light frequencies are contained in each individual diode
• these wavelengths lie in the so-called ‘optical window’ and can therefore penetrate deeper into the tissue to achieve optimum light absorption and therapeutic effect
• made from high-quality materials
• short treatment time of only 2-3 minutes on the legs and 5 minutes on larger muscle groups makes the application easy and practical in hectic everyday life
• size: 40 x 40 cm
• 2 elastic bands and Equine LTS logo bag included for storage
• areas of application: Ligament injuries, scar tissue, lactic acid breakdown, wound healing, promoting hair growth, muscle injuries/muscle soreness

Material

• neoprene, LED light strands, fabric, elasticated straps with Velcro fastener, lithium battery

Important instructions

• only use the device on a dry, clean surface
• the horse must be tied up and supervised during treatment
• do not fold, step on or place heavy objects on the LED light surfaces
• do not bend the light strips - this is not covered by the warranty
• the manufacturer accepts no liability for damage caused by improper use
• optical spectrum: 660 - 900 nm

Battery operation and charging

• the battery is located on the side of the device and has an on/off switch
• to ‘ON’ to charge the battery
• the battery is charged and tested on delivery
• do not store the battery in a cold place, otherwise it will discharge more quickly
• disconnect the LTS from the battery during the charging process
• only use the charger supplied - other chargers can damage the device!
• plug the charger into the socket - green indicator - connect and switch on the battery - indicator changes to red - when the indicator is green again, the battery is fully charged
• the battery discharges more quickly at temperatures below 5 °C

Care instructions

• carefully clean the LED light with cotton buds and isopropyl alcohol
• do not wash the device and store in a dry place
• store in the supplied storage bag
